[ Samsung Steglos LED Videowall ]

public-display

Presentations & Videos

Samsung UD55A TFT-LED Videowall:

Larger, slimmer, lighter. With their viewing angle of 178 °, significantly higher brightness and Full HD resolution, the Samsung displays are ideal to support your presentation or event effectively!

The Samsung UD55A LED LFD is the spectacular display designed specifically to deliver even the largest images with clarity and as less image loss possible with its super-slim bezel. When the video wall is assembled, bezel-to-bezel rounds up to only 5.5mm, bringing nearly seamless experiences into your business. Unlike many of the video wall available in the market, the UD Series provides Full HD Resolution and easy installation through our unique LFD Accessories. Digital loop out through various ports allow up to 100 LFDs to display equal picture quality throughout the whole video wall. Remote controlling is supported through RJ45 LAN MDC feature along with the RS232C daisy chain MDC.
 Samsung UD55
Because of the screen size of 55 "/ 138cm per display a 2X2 Samsung LED videowall becomes a real option to a conventional 3x3 wall.
Samsung UD55

The picture shows the relative sizes of the new Samsung UD 55 "LED video wall (2x2) in relation to a conventional 42" video wall (3x3).

Technical Data:


Panel:
LCD Technologie a-si TFT/DID
Backlight Technologie LED
Screen Size 138,68 cm (55 Zoll)
Resolution: 1920 x 1080, Pixel Pitch 0,630 mm
Brightness 700 cd/m²
Contrast Ratio 3.500:1
Contrast (dynamically) 10.000:1
ResonseTime 8 ms (G/G)
Viewing Angle (h/v) 178°/178°
Frequenzen:
Horizontal 30 - 81 kHz
Vertical 56 - 85 Hz
Colours 16,7 Mio.
Signal:
Signal analog, digital
Ports: 2 x HDMI™, 2 x D-VDI (In / Out), 15pin D-Sub, Composite Video
Plug & Play DDC DDC 2B
Electricity Consumption:
Standby < 1 W
In operation 225 W
EnergyStar 5.0
General Spezifications:
Colour black
Ultra thin frame: 1,8 mm (below/right) 3,7 mm (on top/left)
Wall mount VESA Norm 600 x 400 mm
Mac-compatiblea
TÜV GS
EMI CE
Specific Features:
tRS-232C Loop
DVI Loop Out für Video Walls
Video-Wall-support (up to. 10 x 10 Displays)
PiP (Picture-in-Picture)/PbP (Picture-by-Picture)
MDC über RS-232C ja
MDC über RJ-45 ja
On/Off Timer
NotePC Dockingstation
Mass and weight:
Mass without stand (B x H x T) 1215,3 x 686,1 x 96 mm
Weight 24 kg
